Custom Blade
Custom Blade —Reverse-Engineered
Custom industrial blade reverse-engineered from your worn sample or drawing, with material and hardness tuned to the application.

Typical application photo. Final geometry, finish and marking are confirmed in the engineering quotation.
Custom Blade — custom
Custom Blade —Reverse-Engineered
Custom industrial blade reverse-engineered from your worn sample or drawing, with material and hardness tuned to the application.
- Material
- Specified per application —D2, SKD11, DC53, M2 HSS, H13, carbide
- Hardness
- Specified per application —HRC 50±4
- Coating
- As specified per drawing
- Category
- Custom Blades
Typical applications
The specifications on this page are typical for the product family. Final dimensions, tolerances, hardness and coating are confirmed in the engineering quotation. Contact us for a drawing or a quote against your application.
Detailed specifications available on request.
Primary applications
- Reverse-engineered from sample
- Drawing-to-part
- Co-developed geometry
Compatible machines
Geometry and tolerances are configured per OEM specification. Compatible with major slitter, winder, sheeter and shear lines.
- Slitter-rewinders
- Cut-to-length
- Guillotine shears
- Swing-beam shears
- Granulators
- Shredders
Overview
If your blade is obsolete, vendor-locked, or simply worn beyond recognition, we can reverse-engineer a replacement from the worn part. Send us the part (or a 3D scan / drawing), tell us what is failing on it, and our engineering team will design a replacement that fits —often with an upgraded material grade or geometry.
Process
- Receive sample / drawing. Send by courier or as STEP / IGES / DXF.
- CMM measurement. We measure the critical features on the worn part and reconstruct the geometry.
- Material recommendation. Based on the wear pattern and your process data (line speed, material cut, downtime cost), we propose a material grade and hardness.
- Drawing approval. We issue a 2D / 3D drawing for your written sign-off before any steel is ordered.
- Manufacture and deliver. Same QC chain as our standard SKUs —CMM inspection report, hardness, surface records shipped with the part.
When Reverse-Engineering Helps Most
- The original blade is no longer available from the OEM.
- The OEM lead time is too long for your maintenance window.
- The original blade is failing prematurely —we can usually identify why and propose an upgrade.
- A second-source supplier is needed for risk management.
Materials We Work In
D2, SKD11, DC53, M2 HSS, M4 HSS, H13, H21, tungsten carbide tipped and solid carbide, plus PVD coatings (TiN / TiCN / CrN / DLC).
TODO —send your sample or drawing to [email protected] to start a reverse-engineering case. Response within one business day.
Order or Custom Version
Ready to orderor need a custom version?
Send your drawing, your worn blade, or a written spec. We will respond within one business day.
- CMM-verified reverse engineering
- Geometry upgrade on request
- NDA on first email
drawing or worn blade → spec → quote → lead time
